The system comprises a total of 27 belt conveyors with a combined installed conveying length of 2000m. The configuration includes 8 feeders, 1 large-incline conveyor, and 2 belt conveyors equipped with mobile unloaders. Two tensioning methods are adopted: gravity take-up and screw tensioning. The conveyed material is gold ore.

• BW 1400mm: conveying capacity 842-1610t/h, belt speed 1.25-1.6-2.0m/s
• BW 1200mm: conveying capacity 842-1200t/h, belt speed 1.6-2.0m/s
• BW 1000mm: conveying capacity 700-969t/h, belt speed 2.0m/s
• BW 500mm: conveying capacity 2t/h, belt speed 0.6m/s
